from Mini Embedded System
to 4HE Edge Server
Embedded systems and industrial computers from A to Z
Thanks to the modular design of our systems, we offer robust solutions for almost all requirements and applications.
From the industrial Raspberry PI to fanless high-performance systems with server CPUs and dedicated workstation graphics cards for AI and edge computing workloads.
All series systems are usually available within a few working days and are delivered ready for use as turn-key solutions.
Everything outside the world of series systems we develop with you, according to your specifications, for your exact application.
Here too, having both development and production under one roof ensures short communication channels and quick results.
Serviceliste
-
Box IPC / Embedded SystemsListenelement 2
Economical and cost-effective systems that are ideal for Internet of Things (IoT) or digital signage applications. These systems are easy to integrate and are available with many different mounting systems.
-
Fanless Industrial PCListenelement 1Extremely powerful and easily expandable IPC systems for high CPU and GPU workloads. The robust industrial computers are ideal for AI applications and edge computing.
-
Special Systems
Systems for special applications and particularly difficult environmental conditions:
- DIN rail PCs for control cabinets and electrical distribution boards
- Splash-proof and dust-proof systems (IP65)
- High-temperature IPCs with wide operating temperature ranges
- Special designs
-
19" Industrial ComputerListenelement 3Fanless 19" industrial computers specially developed as edge servers for AI and visualization tasks. This series consists of scalable short rack systems from 1U to 4U, with front IO or back IO.
-
Panel PC & Industrial DisplaysListenelement 4
Modular panel PCs and industrial displays - individually configurable. All HMI solutions are equipped with the latest PCAP touch sensors, IP65 protection and extremely flat full metal casing. They are reliable, durable and extremely easy to install.
-
IoT & Networking
Industrial IoT gateways, fanless desktop firewalls and 19" networking appliances for IT and OT environments in all performance classes: from industrial Raspberry PI to Intel Xeon.
Your request - our solution
Temperature
In industrial use, as well as when operating in vehicles or outdoors, IPCs are exposed to large temperature ranges. Temperature fluctuations must also be taken into account. Commercial standard computers usually cover the range 0..35°C, while fanless TX-Team IPCs work reliably, at least in the range 0...45°C, sometimes -40 .. 75°C, 24/7, even under continuous full load.
IP Protection Class
As far as dust and splash protection according to IP standards is concerned, we have systems up to protection class IP65 (complete dust protection, protection against jet water).
Systems that are protected from dust, dirt and moisture on all sides are suitable for special industries such as medicine, the food industry, laboratories and agricultural operations as well as outdoor use.
Systems that are protected from dust, dirt and moisture on all sides are suitable for special industries such as medicine, the food industry, laboratories and agricultural operations as well as outdoor use.
Shock and Vibration
Depending on the application, IPCs can be exposed to increased mechanical effects. Vibrations and shocks - for example from machines or in vehicles - pose a risk to plug connections and socketed CPUs and RAMs.
System designs without cables, with soldered CPUs, secured screw connections, mechanical protection and/or anti-vibration fill for RAMs according to MIL standards effectively counteract this risk.
Maintenance-Free
Fanless systems with flash or SSD storage have no moving parts and therefore no mechanical wear.
Closed heat sink casing direct the power loss outwards via heat pipes or heat spreaders and release it into the environment.
This means that no foreign objects can enter the system, so no cleaning is necessary.
Closed heat sink casing direct the power loss outwards via heat pipes or heat spreaders and release it into the environment.
This means that no foreign objects can enter the system, so no cleaning is necessary.
24/7
TX-Team IPCs are basically designed for 24/7 operation - even under permanent full load.
Generously dimensioned cooling systems, high-quality components and extensive testing ensure that TX-Team systems run trouble-free for 10 years or more.
Generously dimensioned cooling systems, high-quality components and extensive testing ensure that TX-Team systems run trouble-free for 10 years or more.
For particularly critical applications, integrated UPS', redundant power supplies, remote maintenance functions (predictive maintenance) and RAID systems are available.
Interfaces
While specialized embedded systems offer a reduced setting and often use headless operation,"larger" industrial computers usually have a rich variety of interfaces. These include several graphics interfaces for multi-monitor operation, dual GLAN controllers, audio, USB 2.0 / 3.0 / 3.1 and at least two COM interfaces.
If required, up to eight RS232 / 422 / 485 ports are possible.
If required, up to eight RS232 / 422 / 485 ports are possible.
This makes it easy to integrate these systems into Modbus, Ethercat and other environments.
Additional communication interfaces such as LoRA, Sigfox, WLAN, 3G/4G as well as CAN and various field buses are either already integrated or can be expanded using add-on modules.
Digital and analog GPIOs are suitable for direct connection to sensors and actuators.
Software
Depending on the application, a Windows or Linux operating system is the better choice. Our IPCs generally support both. We can also continue to supply "retro-fit" systems for operating systems up to MS-DOS without any problems.
In addition, there is the entire range of Linux and Microsoft Embedded operating systems, such as Windows 10 and 11 IoT Embedded Enterprise.
We have also released Microsoft's server operating systems and all common virtualization hosts for many IPCs and edge servers.
In addition, there is the entire range of Linux and Microsoft Embedded operating systems, such as Windows 10 and 11 IoT Embedded Enterprise.
We have also released Microsoft's server operating systems and all common virtualization hosts for many IPCs and edge servers.
We can generally evaluate software/image compatibility quickly and free of charge.
Whatever application you want to run on your IPC: Codesys, LabView, WinCC, or your own software, we will be happy to help you with the implementation.
Whatever application you want to run on your IPC: Codesys, LabView, WinCC, or your own software, we will be happy to help you with the implementation.
Long-Term Availability
Evaluating new hardware and checking for compatibility can be time-consuming.
In order to avoid unnecessary system changes, the product range of all TX-Team IPCs is modular, platform-based and designed for long-term availability. This is 5 years by default, but often up to 15 years.
In order to avoid unnecessary system changes, the product range of all TX-Team IPCs is modular, platform-based and designed for long-term availability. This is 5 years by default, but often up to 15 years.
Successor systems are usually mechanically identical, compatible in many areas and often even image-compatible with the respective predecessor models.
Certifications
CE, FCC, ... as well as application- or industry-specific market certifications: We ensure that the criteria are met or - if requested - we can carry out the certification for you via an accredited laboratory.
Accessories
Whether it's a DIN rail, VESA or wall mounting kit, whether it's a 10" or 19" bracket: In our online shop, you will find a whole ecosystem of accessories for TX-Team systems. If you can't find what you're looking for here: ask us - we'll find the right solution!
